CE Floor Spring

JU-68A

The main function of floor spring is to ensure that the door can be opened properly or that it can be closed to its initial position in an accurate and timely manner, normally used in frame-less and frame glass door.

Category:

Floor Spring

Key words:

Glass Gate
Inquiry

Product Details

Product Parameters

Product Name Hydraulic Floor Spring
Item Number JU-68A
Material Iron And 304 Stainless Steel
Finish SSS/PSS
Max. Door Width ≤1150mm
Max. Door Weight 120kg
Max. Opening Angle 120°
Dimension(L×W×H) 308×108×41mm

Product Advantage

Hydraulic Cylinder Block The hydraulic floor spring has superior cushioning performance whether it is in extremely low or high temperature, it can guarantee the normal operation of the machine
Two Stage Speed Control First stage is Closing control from 90° to 20°, second stage is Latching control from 20° to 0°
Double Cylinder Design Design of double cylinder can improve the product performance such as locking force has better wind resistance due to the use of double-piston
Different Design Of Spindles Our spindles are available for different standard such as DORMA, GEZE, NEWSTAR, MAB, VVP and so on
Customized Design Cover Panel, Body, Cover Plate and Package all can provide OEM services. Logo can be engraving, lasering or printing depends on the performance of customer.

Certification





Why Choose Kaida As Your Business Partners?

OEM Design

 Kaida can provide OEM design services for product and packaging. The product configuration can be changed based on client's requirment. Design of logo can be engraving, lasering or printing depends on the performance of customer.

Certification

International ceitifications such as CE, UL, EN1634 and EN1154 have all been obtained by passing an annual test in an authoritative laboratory.

Product Diversification

Kaida can provide integrated solutions for oversea project based on our complete supply chain. Besides for glass door accessories, we also manufacture the accessories used in wooden door and aluminum frame door as well.

Product Development

Kaida evolved as a global player through manufacturing unconventional products based on drawings and templates provided by customers to meet their diverse needs and desires in various application scenarios.
